White Woven Filter Fabric Geotextile Membrane For Soakaway

  • 1
  • 2
  • 3

Brand Name : Wanshengli

Model Number : /

Certification : GB, ISO, SGS

Place of Origin : Anhui, Luan, China

MOQ : 1000sqm

Price : 0.35 USD ~1.5 USD per piece

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 50000 sqm per day

Delivery Time : 5~8 working days

Packaging Details : Woven Plastic bags or as your request

Material : PE

Color : White

Application Scenario : mining,landfill, Pool, reservoir, dam,expressway, railway, etc

Length : 50-200m/roll or as per your request

Width : 1-8m or as your request

Gram Weight : 100g/㎡~1500g/㎡

Sample : Free provided

Package : Woven plastic bag

MOQ : 1000 sqm

Contact Now

Filament Geotextile

Geotextiles are permeable nonwoven fabrics used to separate,filter,reinforce, protect or drain. Geotextiles allow filtration or separation of granular layers in roads and railway applications ,used to protect membranes in landfill applications,used in coastal defence applications and used in landscaping to protect surfaces and structures from weeds and root growth.

Geotextiles are availabel as woven and non-woven .As liner protection, against physical damage, the non wovens are normally the answer.They are made up of fibers of polyester or polypropylene in random directions and punched together by needles during the manufacturing process. It is commenly used to separate layers like clay and drainage and to protect liner from damage.
White Woven Filter Fabric Geotextile Membrane For Soakaway
Product parameter
No.

Item

Index

Specification

 100 150 200 250 300 350 400 450 500 600 800 Remarks
1 Unit area mass deviation,% -6 -6 -6 -5 -5 -5 -5 -5 -4 -4 -4
2 Thickness, mm ≥ 0.8 1.2 1.6 1.9 2.2 2.5 2.8 3.1 3.4 4.2 5.5
3 Width deviation, % -0.5
4 Breaking strength, KN/M ≥ 4.5 7.5 10 12.5 15 17.5 20.5 22.5 25 30 40 Vertical and horizontal
5 Elongation at break, % 40-80
6 CBR bursting strength,KN ≥ 0.8 1.4 1.8 2.2 2.6 3 3.5 4 4.7 5.5 7
7 Equivalent aperture,O99(O35),m 0.07-0.2
8 Vertical permeability coefficient,cm/s KX(10 -1 -10 -3 ) K=1.0-9.9
9 Tear strength 3,KN ≥ 0.14 0.21 0.28 0.35 0.42 0.49 0.56 0.63 0.7 0.82 1.1 Vertical and horizontal

White Woven Filter Fabric Geotextile Membrane For Soakaway
